Extended Life Battery Module for Breas Z2 PowerShell

Have you purchased the Breas Z2 PowerShell to turn your Breas Z1 or Z2 CPAP into a fully self-powered portable CPAP solution when traveling, camping, or to use as a battery backup while at home?

Although your purchase of the Breas Z2 PowerShell included an extended life battery, often times a single battery isn't enough to keep up with your active lifestyle.

If that's the case, the new Breas extended life battery gives you an interchangeable battery module to provide you with as many cordless free nights as you'd like!

Additionally, the new extended life battery by Breas delivers twice the capacity of the original battery.

Having extra extended life batteries that integrates with your Breas PowerShell is also highly recommended  in case you ever encounter power outages, a storm, or a total blackout.

Meaning even if the power is out, you won't have to go without your prescribed sleep therapy treatment.

Furthermore, the rechargeable extended life battery integrated with the Z1/Z2 PowerShell provides you with the smallest integrated CPAP battery option available.

Compatible with the Breas Z1 & Z2 CPAP Machines

Whether you have the Breas Z1 CPAP, the Z2 CPAP or the Z2 Auto by Breas, you are able to use the PowerShell with Extended Life Battery with both lines of CPAP machines!

Enhanced Battery Life for Longer Cord Free Operation

Enjoy even longer cord free operation of your Breas Z1 and Z2 CPAP machines thanks to the Extended Life Battery providing you with twice the battery capacity of the original Breas Overnight Battery.

Even when using at the highest settings (20 cmH2O, Z-Breathe 3), you'll be able to enjoy up to 8.9 hours* of use.

But if you're utilizing lower pressure settings, you should enjoy even longer portable sleep therapy treatment.

*These battery results were obtained via bench testing under simulated operating conditions. Actual run time may vary due to machine settings, machine pressure, and personal breathing.

Not sure how much battery life you have left?

Not to worry, you can quickly check the status of your battery as the built-in screen displays a battery status indicator.

Battery Life & Charge Time:

• Battery Life: Up to 8.9 Hours

• Recharge Time: Up to 12 Hours (Typical Per Battery)

Recharges Directly from Your Breas PowerShell

Your Breas Extended Life Battery is a rechargeable lithium ion battery, which is recharged using the Breas PowerShell and AC power supply (wall outlet).

When it comes time to charge your Extended Life Battery Module, the battery module automatically begins to recharge in the PowerShell when plugged into a wall outlet with the charging cable that came with the purchase of your Breas Z2 CPAP.

Something to point out when using the Z1 or Z2 Auto CPAP machine with the PowerShell, and the time comes to recharge the battery.

Your Breas Z1 or Breas Z2 Auto CPAP machines are not required to be inserted in the PowerShell when your Extended Life Battery Module is charging.

However, if the Z1 or Z2 CPAP are in the PowerShell you'll need to place it in standby mode in order for the battery to charge.

Your Breas PowerShell will not charge your battery at the same time that you are using your Z1/Z2 Auto.

So be sure to plan your charging cycles accordingly.

Or at least around times that you will not need to use the PowerShell with your Breas Z1 or Breas Z2 Auto travel CPAP machine.

Battery Charge Status:

What's Included:

• Breas Extended Life Battery with Shuttle (PowerShell Sold Separately)

Breas Extended Life Battery Specifications:

Capacity: 99.4 Watt-hours

Lifetime: approximately 300 charge/discharge cycles

Shelf life: Batteries are shipped with between 30% and 50% of rated capacity, providing a minimum of 6 months shelf life when stored at 25°C. If storage temperature exceeds 25°C over a 6-month period then shelf life will be reduced and the battery should be recharged periodically.

Storage and transport temperature: -4ºF to +140ºF (-20ºC to +60ºC)

Storage and transport humidity: 10-95% Relative Humidity, Non-Condensing

Battery Technology: Lithium Ion Battery Pack, 4S2P

Battery Module Weight: Approx. 15.5 oz (440g)

Charging Battery: charges when Z1 / Z2 is in standby mode.

Extended Life Battery Module Frequently Asked Questions

Can I Use the Extended Life Battery Module by Itself?

No, you cannot use the extended life battery module without the Breas PowerShell.

How Do I Keep My Extended Life Battery Module from Losing Charge While Not in Use?

Once your Breas Extended Life Battery Module is charged to completion, please disconnect your Z1/Z2 machine from your PowerShell and remove the battery from the PowerShell, or it will slowly drain the battery over the course of 2-3 days.

My Extended Life Battery is Not Charging, What Do I Do?

Make sure you hear a clicking noise when inserting your Extended Life Battery Module into the PowerShell.

If it is still not charging disconnect the Z1/Z2, battery, and power supply and reconnect.

Proceed to recharge your unit again for 10-12 hours.

If it is still not holding a charge, please contact us.

Please keep the following information in mind after charging your Breas Extended Life Battery:

• Disconnect the battery from the PowerShell after a full charge to prevent the battery from slowly draining within a 2-3 day period.
• The battery needs to be charged for 10-12 hours to ensure a full charge.
• The bars of battery life on the LCD screen need to be full, and not blinking.
• The PowerShell battery will not charge while it is operating the Z1/Z2 for treatment. The battery must be charged between treatments.
